VM II 3KVA & 5KVA Inverter
产品详情

VM II 3KVA and 5KVA Off Grid Inverter


This is a multi functional inverter/charger, combining functions of inverter,solar charger and battery charger

to offer uninterruptible power support in portable size. Its comprehensive LCD display offers

user-configurable and easy-accessible button operation such as battery charging current,

AC/solar charger priority, and acceptable input voltage based on different applications.



Main Features:

* Pure sine wave solar inverter

* Output power factor 1

* High PV input voltage range

* Inverter running without battery

* Built-in 80A MPPT solar charger

* Battery equalization function to optimize battery performance and extend lifecycle

* Built-in anti-dusk kit for harsh environment


Specifications:


Model VM II 3000-24  VM II 5000-48
RATED POWER3000VA / 3000W5000VA / 5000W
INPUT
Voltage230 VAC
Selectable Voltage Range

170-280 VAC (For Personal Computers) ;

90-280 VAC (For Home Appliances)

Frequency Range50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)230 VAC ± 5%
Surge Power6000VA10000VA
Efficiency (Peak)90%~93%
Transfer Time10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
WaveformPure sine wave
BATTERY
Battery Voltage24 VDC48 VDC
Floating Charge Voltage27 VDC54 VDC
Overcharge Protection32 VDC63 VDC
SOLAR CHARGER & AC CHARGER
Max. PV Array Open Circuit Voltage500VDC500VDC
Max. PV Array Power4000 W4000 W
MPP Range @operating Voltage120~450VDC120~450VDC
Max. Solar Charge Current80 A80 A
Max. AC Charge Current60 A60 A
Max. Charge Current80 A80 A
PHYSICAL
Dimension, D x W x H (mm)100 x 300x 440
Net Weight (kgs)910
Communication InterfaceUSB/RS232
ENVIRONMENT
Humidity5% to 95% Relative Humidity (Non-condensing)
Operating Temperature-10°C to 50°C
Storage Temperature-15°C to 60°C
